Injured P4.2
Poranit-P4.2 (data sheet)
porous down to the smallest pore
P4.2 is a modified P4 with improved cooling properties. The higher thermal conductivity prevents the mold from heating up too much and has a positive effect
on the accuracy of the molded part and cycle times. P4.2 is available in all sizes
up to 1,200 x 800 x 10-140mm
on the accuracy of the molded part and cycle times. P4.2 is available in all sizes
up to 1,200 x 800 x 10-140mm
Serviceliste
-
DensityListenelement 11,74 g/cm³
-
Nadeldruckhärte shore D / BrinellListenelement 287 / 27 HBW (5/125/10)
-
Pore size / pore quantity // pore size / pore quantityListenelement 316 µm / 22 %
-
E-ModuleListenelement 437,4 kN/mm²
-
Thermal conductivity / thermoconductivity39.2 W / mK
-
Long-term heat resistance250 °C
-
Verglaungstemperatur / Glass transition temperature285,7 °C
-
coefficient of thermal expansion27.4 (x 10-6K-1)
